RS232 Serial Monitoring and Software Kits...

RS232 Com Tap Data Monitor
RCT-001

USB Powered.
RS232 Software, RS232 Drivers & Cable Included.
Easy to Use.
Best Value.
Free Software.
Free Shipping.
$129.95

RS232 to USB
SSP-016

$29.95

RS232 Full Duplex Monitoring Cable
FDC-001

$49.95

RS232 Analog Input Kit or Assembled
DVM-001-1
$69.95

RS232 8-DPDT Relay and Analog Input Kit or Assembled
RC-001-1 $149.95

RS232 Half Duplex Monitoring Cable
HDC-002

$49.95

RS232 serial tools and rs232 serial port monitoring from Virtual Integrated Design!


v1.0 RS232 CPM is our software monitoring program that can be used to observe and record RS232 data. RS232 CPM is easy to use and RS232 setup data can be saved and later retrieved for easy setup of each individual monitored connection. The program requires two availible com ports or our compact RCT-001 USB rs232 tap device for full duplex monitoring. RS232 CPM takes advantage of the .NET framework and is compatible with all new Windows operating systems and PC hardware including 32-bit and 64-bits systems. For Windows 2000, XP, Vista, Win7, Win8, Win10.
Free 32-bit .Net framework 2.0 or 64-bit .NET framework 2.0 is required before installation on 2000 or XP. <screen shot> <download demo> registered version $39.95>. A full version of RS232 CPM is FREE with the purchase of RCT-001 Com Tap.

v1.04 RS232 HCT is a second generation RS232 software application that expands on our earlier programs and makes RS232 communication, development, debugging and troubleshooting easier than ever. RS232 HCT takes advantage of the .NET framework and is compatible with all new windows operating systems and PC hardware including 32-bit and 64-bits systems. For Windows 2000 and XP, 32-bit .Net framework 2.0 or 64-bit .NET framework 2.0 is required before installation. <screen shot> <download demo> registered version $39.95> <RS232 HCT v1.0 Getting Started pdf>.

v6.01 RS232 Hex Com Tool is a serial software terminal program that can be used to communicate with just about any rs232 peripheral. This reliable serial software program is great for embedded developers and it can transmit and receive serial data in Hex or ASCII. RS232 Hex Com Tool is easy to use and rs232 setup data can be saved for multiple peripherals and later retrieved for easy setup of each individual device. Retrieving the setup can even open the com port. Top features include: non standard baud rates, click to send, helpful right click menus, etc. New features in RS232 Hex Com Tool version 6.0 include: Quick click window, auto detect hardware, auto add bytes, delay between bytes, add and calculate checksum and Modbus CRC, stay on top, variable window transparency, many main and right click menu additions. v6.01 adds fix for CR/LF in Ascii mode. (Not for Windows Vista or 7). <screen shot> <download demo> <registered version $39.95> <RS232 Hex Com Tool v6.0 Getting Started pdf>

v4.0 Is our thoroughly field tested and reliable software tool for serial monitoring, troubleshooting and logging rs232 communication. A laptop PC and this com port monitor give you a powerful, portable and sturdy tool to aid in designing and logging rs232 data between peripherals and hosts. Monitor rs232 data with a separate PC for total isolation of cpu cycles or monitor data with the same PC that is running the application by using more hardware com ports (com driver is not changed). <cable hook-up diagrams>  <more hook-up's>  <cable data>. Use on any PC with Windows 95 up to XP (Not for Windows Vista or 7) with standard or USB/RS232 com ports with this rs232 data monitor. <screen shot> <download demo> <registered version $39.95>

v1.0 Shows serial data transmitted and received from an rs232 com port on the same pc with no extra hardware!
View and log RS232 data in Hex or Ascii mode. Format the serial port data in a variety of ways including: commas and/or spaces between bytes, substitute chars for non-print characters in Ascii mode, new line on specific byte, new line after a specific number of rs232 bytes are received. RS232 Stealth Monitor can automatically show the com ports attached to your pc or generate a standard list up to COM100. This serial monitor can log rs232 data to disk for a pre-determined amount of times and increment the file name starting at a specified number. Other options include: Stay on top, change transparency, add name, reset time, time stamp. (Not for Windows Vista or 7). <screen shot> <download demo> <registered version $39.95>


Get all three, RS232 Hex Com Tool v6.01, RS232 Stealth Monitor v1.0 and RS232M Com Monitor v4.0 for $99.95, a savings of $18!
With this suite you get all the software you need to develop, log and troubleshoot RS232 communication quickly and easily. Add monitor cables and possibly serial ports for older equipment or PLC's (where onboard software can't be added).
Download registered Deluxe RS232 Communication and Monitoring Suite zip file or get CD.


Get both RS232 Hex Com Tool v6.01 and RS232M Com Monitor v4.0 and save $14.95! Download zip file or get CD.

Note: Customers who have purchased any major version of any of our RS232 software programs can receive any minor version change free by request.

A list of customers that tried our software and purchased the full version include: (to name a few):
NASA, Comcast, Perkin Elmer, Cannon, Eaton, Sony, Honywell, Simtek, Boeing, Motorola, Caterpillar, RSA Security, CCCS, GE, Lam Research, Hitachi, Siemens AG, Dow Chemical, Moog, Rayethon, Saab, etc.

Schematics for microcontroller RS232 data acquisition/interface circuits along with the code and hex files for each circuit. Starting with a simple RS232 interface and moving on to ADC's, DAC's, buffered counter circuits, voltage switches, RS232 isolation, etc.
Most of the circuits are built using PIC microcontrollers.
RS232 controlledDVM-001 digital volt meter kit with PC interface and in-circuit programming. This board is powered from the rs232 line and includes c0mplete source code!

  Interface projects for the PC using C++ Builder. The first project is a RS232 relay interface to visually control 8 relays. The relay schematics and micro code for this project can be obtained on our micro stop page.
Our second project is the RS232 Virtual Dvm2000. The project emulates a Digital Voltmeter with a small visual interface. The RS-232 hardware for this project can be found on our micro stop page. This small, inexpensive circuit is powered from the RS232 port.

Ask about our design services. We offer design services for complete project development of digital and analog microcontroller based interfaces with circuit board and enclosure! Email us your requirements and we will email a quote. Better prices on quantity orders.
